Description
Part Number | B5101V400CC-A |
---|---|
Material | 316L Stainless Steel |
Seat | FKM |
Size | 4″ |
Pressure Rating | 85 PSI |
Vacuum Rating | 0.4 inches Hg at 68°F |
Temperature Range | 15°F to 200°F (-9.4°C to 93°C) |
Mandatory Pkg/Box Qty | 1 |
Weight Lb | 13.2950 |
Specifications
- Break torque: 450 in. lbs.
- Flow coefficient: 800 CV
Features
- Clamp End
- 100% hydraulic tested / 100% inspected
- Field serviceable (no special tools required)
Construction
- All wetted surfaces are sanitary finished to < 32Rₐ
Note
- Pressure rating (PSI), Flow Coefficient (CV) and Break Torque (in. lbs.) information supplied is based on water media at 68°F / 20°C
- Handle is not assembled when shipped. To order with handle assembled on the valve please request assembly in the special instructions of your order.
